The raw material is green RVD grade diamond, it featured with sharp or blocky Particle Shape, monocrystalline structure, concentrated particle size distribution, low magnetic susceptibility, low impurities and excellent brittleness, perfect for grinding and polishing high-hardness materials such as stones, cemented carbide, ceramics, gems, and optical glass.
The raw material is economical diamond, which is made by a special crushing, shaping and grading process. The shape is semi-block with sharp edges and good particle concentration. Has good sharpness.
Suitable for manufacturing economical diamond tools and grinding pastes and liquids that require fast and free grinding.
Model
Grit |
0-0.25 | 0-0.5 | 0-1 | 0.5-1 | 0.75-1.25 | 1-1.5 | 1-2 | 1-3 | 2-3 | 2-4 | 2-5 | 3-6 | 4-6 | 4-8 | 5-10 | 6-12 | 8-12 | 8-16 | 10-18 | 10-20 | 12-22 | 15-25 | 20-25 | 20-30 | 22-36 | 20-40 | 30-35 | 30-40 | 35-45 | 40-50 | 45-55 | 40-60 | 45-70 | |
D50(microns) | 0.1-0.2 | 0.2-0.4 | 0.4-0.6 | 0.6-0.8 | 0.9-1.1 | 1.1-1.3 | 1.3-1.5 | 1.6-2.0 | 2.0-2.3 | 2.4-2.9 | 2.9-3.5 | 3.5-4.3 | 4.3-5.3 | 5.3-6.1 | 6.2-7.6 | 7.6-8.7 | 8.8-9.9 | 10-11.2 | 11.3-13 | 13.1-15.4 | 15.5-17.5 | 17.6-19.3 | 19.4-21.9 | 22-25 | 25-27 | 27-30 | 30-34 | 34-36 | 36-39 | 39-43 | 43-46 | 46-49 | 49-55 | |
JGM | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ | ☆ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ||
★Available | ||||||||||||||||||||||||||||||||||
☆Customizable |
